face drivers is the upgrade product to instead the traditional lathe clamping apparatuses such as Lathe Dog and it can stir the dishes and the like on the lathe, it's used to chuck the axis class components which the both ends have the centre bores, face driver is the new generation of machine tool accessories which rapidly rises to the year internationally.
On the other hand, face drivers are used in manufacturing and machining operations to apply force to a workpiece face, allowing it to be machined or worked on. They are typically used in conjunction with a lathe or milling machine, and their design and specifications are tailored for these applications.
face drivers of with drive disks are mechanical clamping systems which are suited for soft green as well as hard tooling. in application, they feature maximum flexibility and high robustness.
traditional jigs have to clamp the work-piece outer annulus while face drivers needn't have to. FD depends on the jaw to actuate the work-piece the end faces and making it revolving along with the main shafts of lathes.
once chucked, face drivers can process the work-piece span. It does't have to turn around to chuck, so can save at least time of above to chuck the non-cutting time. the precision of each related surface mutual position is advanced after the processing between the work-piece.
the clamp force is free from the influences of rotational speed of the main shafts, especially adapting the request of high speed turning. when the work piece end surface has time the big position error to the middle line, it can still guarantee work-piece reliably clamped.
the mounting of the face driver is determined by your machine spindle. depending on the type of face driver, three different mounts are available: shank, flange, or chuck mount.
the face drivers synthesis processing efficiency is high, and labor intensity of operators can be reduced remarkably. face drivers can achieve loading and unloading in the condition of ceaselessly working, not only can further enhance the production efficiency, but also in favor of reducing the energy consumption, prolong the life span of equipments.
the entire surface of the work piece can be tooled and finished by clamping with a maximum of torque transmission. when choosing a face driver you first need to know the diameter of the finished workpiece. compare that diameter to the driving diameter range that is stated at the top of each page.
for longer tool life and best results we recommend you do not exceed the following tailstock force capacities for face drivers. each pin individually compensates for any irregularities in the face until all of the pins are fully engaged. under the increasing axial load, the drive pins penetrate the workpiece completing the clamping operation, while the center point maintains the axis of rotation.
